Platina Integrated Streamer
R69,990.00
The PLATINA series marks a leap forward in design, application and implementation for QUAD. This new flagship seamlessly blends QUAD heritage with a thoroughly modern digital core.
| Model | Platina Stream |
| General Description | Network Player |
| Design Philosophy and Core Technology | ES9038Pro 32-bit DAC |
| 4.3″ (800x480px) Large Size full view, full colour IPS LCD screen | |
| QUAD Platina Stream streaming technology (IEEE 802.11 a/b/g/n/ac) | |
| Native support for Roon Ready, Spotify Connect, TIDAL Connect, | |
| Qobuz Connect,TuneIn Radio and Plex | |
| Gapless Playback | |
| USB storage, flash drive, USB hard disk (Single-partition FAT32, | |
| exFAT and NTFS only) Android/iOS App Control | |
| Ethernet 10/100/1000 Base-T Ethernet, Auto-Negotiation | |
| Inputs | 1 x Network Streaming,1 x PC USB (USB B),1 x 12V trigger |
| Outputs | 1 x RCA,1 x XLR,1 x 12V trigger |
| Supported File Formats | DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD) |
| PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF | |
| Compressed (Lossy) Audio: MP3 | |
| Sampling Frequency | PCM: 44.1kHz-768kHz |
| (Supports 705.6kHz/768kHz fixed-point via streaming function) | |
| DSD: DSD64, DSD128, DSD256, DSD512 (Native) | |
| Digital Section | |
| Digital Output Intensity | 500 +/- 50mVpp |
| Output Impedance | 75 ohm |
| Frequency Response | -0.01dB (20Hz-20kHz,ref.1kHz) |
| Max. Sampling Frequency | 192kHz/24bit |
| Digital Output | 1 x Coaxial , 1 x Optical |
| D to A Converter | |
| Variable Output Voltage | 0 – 2.05Vrms |
| DAC | ES9038Pro |
| Frequency Response | +/-0.5dB (20Hz-20kHz ref.1kHz) |
| Total Harmonic Distortion | <0.001% (1kHz@2.05Vrms ) |
| Max. Sampling Frequency | 768kHz / 32bit |
| Signal-to-noise Ratio (A-weighted) | >116dB (RCA) >120dB (XLR) |
| Output Impedance | 120 ohm |
| General | |
| Standby Power Consumption | <0.5W |
| Net Weight | 11.8Kg |
| Gross Weight | 13.6Kg |
| Dimensions (mm) (W x H x D) | 445 x 134.5 x 348mm |
| Carton Size (mm) (W x H x D) | 500 x 225 x 450mm |
| Finish | Black/Silver |
| Power Requirements (depending on region) | |
| Safety Regulation Conformity | 220-240V ~ 50/ 60Hz |
| 100-120V ~ 50/ 60Hz | |
| Standard Accessories | Power Cord, Remote Control, User Manual |
