Quad 303
Quad 303 - Image 2

Quad 303

R26,990.00

2 in stock

Very few Hi-Fi components are as instantly recognisable as the QUAD 33 and 303, and for that we make no apologies!

Still one of the most popular models in the history of one of the world’s most poignant Hi-Fi brands, the QUAD 33 and 303 are benchmarks in almost every angle of desirable audio equipment – performance, reliability, industrial design, value and musical romance.

ModelQUAD 303
General DescriptionPower Amplifier
Design Philosophy and Core TechnologyClass AB Power Amplifier
QUAD 303 Triples Output Stage
Custom 200VA Toroidal Transformer
Stereo/Bridge mode selection
Inputs1 x Line, 1 x XLR
Outputs1 x 12V Trigger
1 x Stereo Speaker, 1 x 12V Trigger (Link)
Power Amplifier Section
Gain+29dB
Rated Power OutputStereo: 2 x 50W (8 ohms, THD<1%)
Stereo: 2 x 70W (4 ohms, THD<1%)
Bridged: 140W (8 ohms, THD<1%)
Bridged: 170W (4 ohms, THD<1%)
Frequency Response20Hz – 20kHz (+/-0.3dB)
Total Harmonic Distortion (THD)<0.002% (1kHz)
Input Impedance15k ohms (Line)
22k ohms (XLR)
Input Sensitivity700mVrms (Line)
1.5Vrms (XLR)
Signal-to-Noise Ratio (S/N)> 108dB (A – weighted)
Max. Output Current10A
General
Standby Power Consumption<0.5W
Net Weight8.4kg
Gross Weight9.5kg
Dimensions (mm) (W x H x D)120 x 176 x 325
Carton Size (mm) (W x H x D)226 x 312 x 462
FinishClassic QUAD Grey
Power Requirements (depending on region)220 – 240V – 50 / 60Hz
100 – 120V – 50 / 60Hz
Standard accessoriesPower Cord, Remote Control, User Manual
